Round Neon

This Series offers architectural-grade, 80+ CRI LED neon in multiple static white and color outputs. This is a durable, outdoor/wet-rated (IP68) product that is UV, Chemical, & Saltwater Resistant. Multiple lead options include back, left, right or bottom as standard or special order injection molding for seamless lighting.

UL Certified/ yellow & red are Wildlife Certified for safe lighting along the coast. All series are 3.7 watts/ft with a max run of 24.6 feet. Cut marks are 3.28″ for all options, except red/yellow/DRGB is 4.92″.  Install of the Flex Neon Round Series can be in the custom neon channel or with clips to create a unique design.

Specifications

Binning

3-step MacAdams

Certifications

cULus Listed, RoHS Compliant, Wildlife Safe

Color Temperature

2700K, 3000K, 3500K, 4000K, 5000K

CRI

80

Environment

Damp, Wet

Lumens / Ft

5, 10, 16, 52, 53, 90, 130, 145, 155, 159, 160

Operating Temp

-13˚ to 113˚F (-25˚C to 45˚C)

Voltage

24

Warranty

3 Years, 54,000 Hours

Wire Size

18 AWG, 2-wire

Wattage

3.7, 4.6
